Aluminium Balls
Ball Bearing
Lightweight, Non-Ferrous Precision Balls
Aluminium balls provide a combination of low weight, good corrosion resistance, and non-magnetic properties, making them ideal for a wide range of industrial, mechanical, electrical, and decorative applications.
At Atlas Ball & Bearing, we supply precision-engineered aluminium balls in multiple diameters, grades, and finishes — all produced to exacting tolerances and supplied with full material traceability.
150
Precision Ball Diameter
Manufacturing & Supply
We are capable of manufacturing and supplying loose aluminium balls in nearly every variation of grade, maintaining an extensive stock with sizes ranging from 0.2mm to 150mm in diameter.
Please feel free to rate our products and service or send us your comments by using our form opposite →
Additionally, we offer a bespoke ball manufacturing service, which follows the same process controls and traceability but uses a customer’s own material. For further details, please email us or call +44 (0) 1922 710515.
Why Choose Aluminium Balls?
Aluminium offers several distinct advantages over ferrous materials such as carbon or chrome steel:
Extremely lightweight – approximately one-third the weight of steel.
Corrosion-resistant in many environments, though not as resistant as stainless steel in aggressive or saltwater conditions.
Non-magnetic, suitable for sensitive instrumentation and electrical equipment.
Excellent machinability and polish for both functional and decorative use.
Cost-effective in most cases compared to stainless steel or titanium, depending on grade and application
These qualities make aluminium balls a go-to choice for engineers seeking a lightweight with moderate strength non-ferrous material.
Useful terms and definitions
Batch or Lot:
A defined quantity of balls manufactured under conditions presumed to be uniform and which is considered an entity.
Nominal Ball Diameter:
The diameter value that is used for the general identification of a ball size.
Single Ball Diameter:
The distance between two parallel planes tangential to the actual ball surface.
Diameter Tolerance per Batch:
The allowed difference between the smallest measured ball diameter and the largest ball diameter within the same batch or lot quantity.
Sphericity:
A measure of roundness expressed as the difference between the measured roundness of a ball and a theoretically perfectly round ball.
Surface Finish or Roughness:
A measure of the texture of a surface. It is quantified by the vertical deviations of the actual surface from its ideal form. If these deviations are large, the surface is rough; if they are small, the surface is smooth.
Ball Grades
| Grade | Diameter Tolerance per Ball | Sphericity | Diameter Tolerance per Unit Container | Basic Diameter Tolerance | Maximum Surface Roughness Micro | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| Inch | µ | Inch | µ | Inch | µ | Inch | µ | Inch | µ | |
| 3 | .000003 | 0.076 | .000003 | 0.076 | .000005 | 0.127 | ±.00003 | ± 0.076 | 0.5 | 0.013 |
| More details about Grade 3... | ||||||||||
| 5 | .000005 | 0.127 | .000005 | 0.127 | .00001 | 0.25 | ±.00005 | ± 0.127 | 0.8 | 0.02 |
| More details about Grade 5... | ||||||||||
| 10 | .000010 | 0.25 | .000010 | 0.25 | .00002 | 0.51 | ±.0001 | ± 2.5 | 1.0 | 0.025 |
| More details about Grade 10... | ||||||||||
| 15 | .000015 | 0.38 | .000015 | 0.38 | .00003 | 0.76 | ±.0001 | ± 2.5 | 1.2 | 0.03 |
| More details about Grade 15... | ||||||||||
| 25 | .000025 | 0.63 | .000025 | 0.63 | .00005 | 1.27 | ±.0001 | ± 2.5 | 1.5 | 0.038 |
| More details about Grade 25... | ||||||||||
| 50 | .00005 | 1.27 | .00005 | 1.27 | .0001 | 2.5 | ±.0002 | ± 5 | 3.0 | 0.075 |
| More details about Grade 50... | ||||||||||
| 100 | .0001 | 2.5 | .0001 | 2.5 | .0002 | 5 | ±.0005 | ± 5 | 5.0 | 0.125 |
| More details about Grade 100... | ||||||||||
| 200 | .0002 | 5 | .0002 | 5 | .0004 | 10 | ±.0010 | ± 10 | 8.0 | 0.2 |
| More details about Grade 200... | ||||||||||
| 300 | .0003 | 7.5 | .0003 | 7.5 | .0006 | 15 | ±.0015 | ± 37.5 | N/A | N/A |
| More details about Grade 300... | ||||||||||
| 500 | .0005 | 12.5 | .0005 | 12.5 | .001 | 25 | ±.002 | ± 50 | N/A | N/A |
| More details about Grade 500... | ||||||||||
| 1000 | .001 | 25 | .001 | 25 | .002 | 50 | ±.005 | ± 125 | Not Applicable | Not Applicable |
| More details about Grade 1000... | ||||||||||
| 2000 | .002 | 50 | .002 | 50 | .004 | 100 | ±.005 | ± 125 | N/A | N/A |
| More details about Grade 2000... | ||||||||||
