Polyurethane Balls
Ball Bearing
Tough, Elastic, and Impact-Resistant
Our precision polyurethane (PU) balls combine toughness, elasticity, and impact resistance, making them ideal for sealing systems, vibration damping, rollers, and cushioning applications.
Available in custom diameters, Shore hardness grades, and colours, these balls perform reliably in environments where durability, shock absorption, and wear resistance are critical.
150
Precision Ball Diameter
Why Choose Polyurethane Balls?
Polyurethane’s unique molecular structure allows it to perform in applications where other plastics or rubbers would crack, wear, or deform. It resists abrasion, oil, and impact, and provides quiet operation in mechanical systems.
Key Benefits
-
High impact and abrasion resistance
-
Excellent flexibility and rebound
-
Good resistance to oils, greases, and solvents
-
Noise-reducing and vibration-damping
-
High load-bearing capacity
-
Available in various hardness grades (Shore A or D)
-
Non-marking and wear-resistant
Manufacturing & Supply
We are capable of manufacturing and supplying loose polyurethane balls in nearly every variation of grade, maintaining an extensive stock with sizes ranging from 0.2mm to 150mm in diameter.
Please feel free to rate our products and service or send us your comments by using our form opposite →
Additionally, we offer a bespoke ball manufacturing service, which follows the same process controls and traceability but uses a customer’s own material. For further details, please email us or call +44 (0) 1922 710515.
Applications
Because of their resilience and versatility, polyurethane balls are used across multiple industries, especially where durability and shock absorption are critical.
Typical applications include:
Check valves and sealing systems
Vibration dampers and buffers
Rollers, casters, and conveyor components
Impact protection and surface cushioning
Sports equipment and industrial cleaning systems
Pneumatic and hydraulic devices
Polyurethane balls are available in a range of hardness grades, sizes, and colours, with options tailored for either soft cushioning or high-strength wear resistance.
Why Atlas Ball & Bearing?
UK-based manufacturer and supplier of precision-engineered polyurethane and plastic balls
Custom hardness levels (Shore A–D) and colours available
Consistent quality and dimensional accuracy
Technical guidance for mechanical and industrial applications
Fast UK and international delivery
Related Materials
Explore other performance plastics and elastomers in the Atlas Ball range:
Useful terms and definitions
Batch or Lot:
A defined quantity of balls manufactured under conditions presumed to be uniform and which is considered an entity.
Nominal Ball Diameter:
The diameter value that is used for the general identification of a ball size.
Single Ball Diameter:
The distance between two parallel planes tangential to the actual ball surface.
Diameter Tolerance per Batch:
The allowed difference between the smallest measured ball diameter and the largest ball diameter within the same batch or lot quantity.
Sphericity:
A measure of roundness expressed as the difference between the measured roundness of a ball and a theoretically perfectly round ball.
Surface Finish or Roughness:
A measure of the texture of a surface. It is quantified by the vertical deviations of the actual surface from its ideal form. If these deviations are large, the surface is rough; if they are small, the surface is smooth.
Ball Grades
| Grade | Diameter Tolerance per Ball | Sphericity | Diameter Tolerance per Unit Container | Basic Diameter Tolerance | Maximum Surface Roughness Micro | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| Inch | µ | Inch | µ | Inch | µ | Inch | µ | Inch | µ | |
| 3 | .000003 | 0.076 | .000003 | 0.076 | .000005 | 0.127 | ±.00003 | ± 0.076 | 0.5 | 0.013 |
| More details about Grade 3... | ||||||||||
| 5 | .000005 | 0.127 | .000005 | 0.127 | .00001 | 0.25 | ±.00005 | ± 0.127 | 0.8 | 0.02 |
| More details about Grade 5... | ||||||||||
| 10 | .000010 | 0.25 | .000010 | 0.25 | .00002 | 0.51 | ±.0001 | ± 2.5 | 1.0 | 0.025 |
| More details about Grade 10... | ||||||||||
| 15 | .000015 | 0.38 | .000015 | 0.38 | .00003 | 0.76 | ±.0001 | ± 2.5 | 1.2 | 0.03 |
| More details about Grade 15... | ||||||||||
| 25 | .000025 | 0.63 | .000025 | 0.63 | .00005 | 1.27 | ±.0001 | ± 2.5 | 1.5 | 0.038 |
| More details about Grade 25... | ||||||||||
| 50 | .00005 | 1.27 | .00005 | 1.27 | .0001 | 2.5 | ±.0002 | ± 5 | 3.0 | 0.075 |
| More details about Grade 50... | ||||||||||
| 100 | .0001 | 2.5 | .0001 | 2.5 | .0002 | 5 | ±.0005 | ± 5 | 5.0 | 0.125 |
| More details about Grade 100... | ||||||||||
| 200 | .0002 | 5 | .0002 | 5 | .0004 | 10 | ±.0010 | ± 10 | 8.0 | 0.2 |
| More details about Grade 200... | ||||||||||
| 300 | .0003 | 7.5 | .0003 | 7.5 | .0006 | 15 | ±.0015 | ± 37.5 | N/A | N/A |
| More details about Grade 300... | ||||||||||
| 500 | .0005 | 12.5 | .0005 | 12.5 | .001 | 25 | ±.002 | ± 50 | N/A | N/A |
| More details about Grade 500... | ||||||||||
| 1000 | .001 | 25 | .001 | 25 | .002 | 50 | ±.005 | ± 125 | Not Applicable | Not Applicable |
| More details about Grade 1000... | ||||||||||
| 2000 | .002 | 50 | .002 | 50 | .004 | 100 | ±.005 | ± 125 | N/A | N/A |
| More details about Grade 2000... | ||||||||||
